Moderne UI mit altem SAPGUI und ALV-Grid

Ich habe eine kleine Spielerei gebaut, weil ich eine Möglichkeit brauchte um Parameter ein- und auszuschalten. Die normale Methode mit „X“ und „Space“ oder Checkbox fand ich langweilig und mir kam die Idee, dass es möglich sein müsste, eine etwas modernere Art der Darstellung möglich sein müsste.

Sowas in dieser Art:

Bild: http://pixabay.com

Neue UI

Natürlich sind die grafischen Möglichkeiten etwas beschränkt, aber die Funktionalität, wie man sie von jedem aktuellen Smartphone kennt, müsste machbar sein. In Frage kam nur der ALV-Grid (CL_GUI_ALV_GRID). Ich habe mit dem CL_SALV_TABLE angefangen, aber hier lassen sich die Rahmenlinien nicht ausblenden; das geht leider nur im ALV-Grid.

Und tatsächlich:

Ich habe noch mit ein paar anderen Varianten herumgespielt, aber das Prinzip ist immer das gleiche:

Beschreibung

Das Programm baut aus der Parametertabelle eine neue Parametertabelle, die jeweils für ON und OFF ein eigenes Feld für ein Icon hat. Für die Felder wurde die Hotspot-Funktionalität gesetzt, damit man per Klick den Zustand des Schalters ändern kann.

Um die Funktion „wasserdicht“ zu machen, müsste noch verhindert werden, dass die Spaltenbreite verändert werden kann (passiert schnell beim Klicken auf die ausgeblendete Rahmenlinie in der Mitte):

Geschützte Methoden nutzen für die Methode  SET_RESIZE_COLS.

Code

REPORT zz_swwwwwwitch.

"Dummy parameter do display docker
PARAMETERS p.

CLASS main DEFINITION.
 PUBLIC SECTION.
   INCLUDE <cl_alv_control>.
   TYPES: BEGIN OF ty_param,
            name TYPE string,
            text TYPE string,
            status TYPE boolean,
          END OF ty_param,
          ty_params TYPE STANDARD TABLE OF ty_param WITH NON-UNIQUE DEFAULT KEY.

   METHODS init_grid IMPORTING parent TYPE REF TO cl_gui_container.
   METHODS add_parameter
     IMPORTING name TYPE clike
       text TYPE clike OPTIONAL
       status TYPE boolean OPTIONAL.
   METHODS get_params
     RETURNING VALUE(parameters) TYPE ty_params.

   "Settings color
   CONSTANTS color_on TYPE i VALUE col_positive.
   CONSTANTS color_off TYPE i VALUE col_negative.

   "Settings icons
* CONSTANTS status_icon_on TYPE icon_text VALUE icon_businav_szenario.
* CONSTANTS status_icon_off TYPE icon_text VALUE icon_businav_szenario.

* CONSTANTS status_icon_on TYPE icon_text VALUE icon_led_green.
* CONSTANTS status_icon_off TYPE icon_text VALUE icon_led_red.

* CONSTANTS status_icon_on TYPE icon_text VALUE ICON_oo_class.
* CONSTANTS status_icon_off TYPE icon_text VALUE ICON_oo_class.

* CONSTANTS status_icon_on TYPE icon_text VALUE ICON_oo_object.
* CONSTANTS status_icon_off TYPE icon_text VALUE ICON_oo_class.

 CONSTANTS status_icon_on TYPE icon_text VALUE icon_ps_network_activity.
 CONSTANTS status_icon_off TYPE icon_text VALUE icon_ps_network_activity.

* CONSTANTS status_icon_on TYPE icon_text VALUE ICON_add_row.
* CONSTANTS status_icon_off TYPE icon_text VALUE ICON_remove_row.

* CONSTANTS status_icon_on TYPE icon_text VALUE icon_org_unit.
* CONSTANTS status_icon_off TYPE icon_text VALUE icon_org_unit.

   TYPES: BEGIN OF ty_ui_param,
     name TYPE string,
     text TYPE string,
     status_on TYPE icon_text,
     status_off TYPE icon_text,
     t_color TYPE lvc_t_scol,
     t_style TYPE lvc_t_styl,
   END OF ty_ui_param,
   ty_ui_params TYPE STANDARD TABLE OF ty_ui_param.

 PROTECTED SECTION.
   DATA grid TYPE REF TO cl_gui_alv_grid.
   DATA params TYPE ty_params.
   DATA ui_params TYPE ty_ui_params.

   METHODS set_ui.
   METHODS set_color
     IMPORTING status TYPE boolean
     RETURNING VALUE(color) TYPE lvc_t_scol.
   METHODS handle_click FOR EVENT hotspot_click OF cl_gui_alv_grid
     IMPORTING e_row_id.

ENDCLASS.

CLASS main IMPLEMENTATION.

 METHOD init_grid.

 "Local data
 DATA fieldcat TYPE lvc_t_fcat.
 DATA field TYPE lvc_s_fcat.
 DATA layout TYPE lvc_s_layo.

 "Transform parameter data to display UI
 set_ui( ).

 "Create grid in given container
 CREATE OBJECT grid
   EXPORTING
     i_parent = parent.

 "Set fields
 CLEAR field.
 field-fieldname = 'NAME'.
 field-outputlen = 20.
 field-colddictxt = 'Parameter'.
 field-style = alv_style_font_bold.
 APPEND field TO fieldcat.

 CLEAR field.
 field-fieldname = 'TEXT'.
 field-outputlen = 40.
 field-colddictxt = 'Description'.
 APPEND field TO fieldcat.

 CLEAR field.
 field-fieldname = 'STATUS_ON'.
 field-outputlen = 4.
 field-colddictxt = 'On'.
 field-hotspot = abap_true.
 field-icon = abap_true.
 field-fix_column = abap_true.
 APPEND field TO fieldcat.

 CLEAR field.
 field-fieldname = 'STATUS_OFF'.
 field-outputlen = 4.
 field-colddictxt = 'Off'.
 field-hotspot = abap_true.
 field-icon = abap_true.
 field-fix_column = abap_true.
 APPEND field TO fieldcat.

 "Layout
 layout-stylefname = 'T_STYLE'.
 layout-ctab_fname = 'T_COLOR'.
 layout-no_toolbar = abap_true.
 layout-no_headers = abap_true.

 "Display Grid
 grid->set_table_for_first_display(
   EXPORTING
     is_layout = layout
   CHANGING
     it_outtab = ui_params
     it_fieldcatalog = fieldcat
   EXCEPTIONS
     OTHERS = 4 ).

   "Set handler
   SET HANDLER handle_click FOR grid.

 ENDMETHOD.

 METHOD get_params.
   "return current settings
   parameters = params.
 ENDMETHOD.

 METHOD add_parameter.
   "add parameter to parameter table
   APPEND VALUE #( name   = name
                   text   = text
                   status = status ) TO params.
 ENDMETHOD.

 METHOD set_color.

   CASE status.
     WHEN abap_true.
       "set color for switched on
       color = VALUE #( ( fname = 'STATUS_OFF' color-col = color_on )
                        ( fname = 'STATUS_ON' color-col = color_on ) ).
     WHEN abap_false.
       "set color for switched off
       color = VALUE #( ( fname = 'STATUS_OFF' color-col = color_off )
                        ( fname = 'STATUS_ON' color-col = color_off ) ).
   ENDCASE.

 ENDMETHOD.


 METHOD set_ui.

 "for each parameter
 LOOP AT params INTO DATA(param).

   "check if ui entry exists
   READ TABLE ui_params ASSIGNING FIELD-SYMBOL(<ui_param>) WITH KEY name = param-name.
   IF sy-subrc > 0.

   CASE param-status.
     WHEN abap_true.
       "set parameter switched on
       APPEND VALUE #( name = param-name
                       text = param-text
                       status_on = status_icon_on
                       status_off = 'ON'
                       t_color = set_color( abap_true )
                       t_style = VALUE #( ( fieldname = 'STATUS_ON' style2 = alv_style2_no_border_right )
                                          ( fieldname = 'STATUS_OFF' style2 = alv_style2_no_border_left ) )
                     ) TO ui_params ASSIGNING <ui_param>.

     WHEN abap_false.
     "set parameter switched off
       APPEND VALUE #( name = param-name
                       text = param-text
                       status_on = 'OFF'
                       status_off = status_icon_off
                       t_color = set_color( abap_false )
                       t_style = VALUE #( ( fieldname = 'STATUS_ON' style2 = alv_style2_no_border_right )
                                          ( fieldname = 'STATUS_OFF' style2 = alv_style2_no_border_left ) )
                     ) TO ui_params ASSIGNING <ui_param>.

   WHEN abap_undefined.
     "Set parameter not yet defined
     APPEND VALUE #( name = param-name
                     text = param-text
                     status_on = space
                     status_off = space
                     t_style = VALUE #( ( fieldname = 'STATUS_ON' style2 = alv_style2_no_border_right )
                                        ( fieldname = 'STATUS_OFF' style2 = alv_style2_no_border_left ) )
                   ) TO ui_params ASSIGNING <ui_param>.

       ENDCASE.
     ENDIF.
   ENDLOOP.
 ENDMETHOD.

 METHOD handle_click.
 "read parameter entries
 READ TABLE ui_params ASSIGNING FIELD-SYMBOL(<ui_param>) INDEX e_row_id-index.
 READ TABLE params ASSIGNING FIELD-SYMBOL(<param>) WITH KEY name = <ui_param>-name.

 IF <ui_param>-status_on = status_icon_on OR
   <ui_param>-status_on = status_icon_off.
   "set switch to OFF
   <ui_param>-status_on = 'OFF'.
   <ui_param>-status_off = status_icon_off.
   <ui_param>-t_color = set_color( abap_false ).
   <param>-status = abap_false.
 ELSE.
   "Set switch to ON
   <ui_param>-status_on = status_icon_on.
   <ui_param>-status_off = 'ON'.
   <ui_param>-t_color = set_color( abap_true ).
   <param>-status = abap_true.
 ENDIF.
 "Make changes visible
 grid->refresh_table_display( i_soft_refresh = abap_true ).
 ENDMETHOD.

ENDCLASS.

INITIALIZATION.

 DATA(main) = NEW main( ).

 main->add_parameter( name = 'DISPLAY_TECH_DESCR' text = 'Display technical description' status = abap_true ).
 main->add_parameter( name = 'DISPLAY_VALUES' text = 'Display values' status = abap_false ).
 main->add_parameter( name = 'AUTOSAVE' text = 'Autosave' status = abap_true ).
 main->add_parameter( name = 'INST_CALC' text = 'Instant calculation' status = abap_undefined ).

 main->init_grid( NEW cl_gui_docking_container( ratio = 60 side = cl_gui_docking_container=>dock_at_bottom ) ).

AT SELECTION-SCREEN.
 "Enter on selection screen displays current parameters
 DATA(params) = main->get_params( ).
 cl_demo_output=>display_data( params ).
